PolyMax™ PETG

坚韧PETG
Nano Reinforcement™ (纳米增强技术)

Description

PolyMax™PETG提供比其他PETG更好的机械性能,应用广泛,是一款非常优秀的全能选手,在易打印性、耐热性、耐用性和强度上表现出色。可用于功能性原型、终端产品、支架、备件和机器人部件等。



极其坚韧的PETG
优秀的全能选手
良好的层间附着力

Characteristics

Printing Temperature:

230˚C - 240˚C

Bed Temperature:

70˚C - 80˚C

Printing Speed:

30mm/s -50mm/s

Fan:

OFF-20%

Direct Drive Retraction Distance:

3mm

Direct Drive Retraction Speed:

40mm/s

Indirect Drive Retraction Distance:

1mm

Indirect Drive Retraction Speed:

20mm

Drying Settings:

65˚C for 6h

Dry Settings Notes:

(Only if the material has absorbed moisture)

Colors

Colors

No SKUs found!

Series

Specifications

PolyMax™ PETG

print
settings

Printing Temperature:
230˚C - 240˚C
Bed Temperature:
70˚C - 80˚C
Printing Speed:
30mm/s -50mm/s
Fan:
OFF-20%
Direct Drive Retraction Distance:
3mm
Direct Drive Retraction Speed:
40mm/s
Indirect Drive Retraction Distance:
1mm
Indirect Drive Retraction Speed:
20mm
Recommended Support Materials:
PolyDissolve™ S1
Dry Settings:
65˚C for 6h
(Only if the material has absorbed moisture)

MEchanical Properties

(XY)Young's Modulus (MPa):
1784.2 ± 17.6 MPa
ISO 527, GB/T 1040
(Z)Young's Modulus (MPa):
1614.2 ± 92.1 MPa
ISO 527, GB/T 1040
(XY)Tensile Strength:
38.6 ± 0.4 MPa
ISO 527, GB/T 1040
(Z)Tensile Strength:
28.3 ± 0.9 MPa
ISO 527, GB/T 1040
(XY)Elongation at break(%):
13.1 ± 1.8 %
ISO 527, GB/T 1040
(Z)Elongation at break(%)
2.6 ± 0.51 %
ISO 527, GB/T 1040
(XY)Bending Modulus (MPa):
1617.1 ± 57.3 MPa
ISO 178, GB/T 9341
(XY)Bending Strength (MPa):
57.3 ± 0.8 MP
ISO 178, GB/T 9341
(XY)Charpy Impact Strength:
10.0 ± 1.2 kJ/m2
ISO 179, GB/T 1043

Thermal Properties

Glass Transition Temperature:
79 °C
DSC, 10°C/min
Melting Temperature:
79 °C
DSC, 10°C/min
Heat Deflection Temperature
(1.8MPa):
72.3 °C
ISO 75 1.8MPa
Heat Deflection Temperature
(0.45MPa)
75.7 °C
ISO 75 0.45MPa
Vicat Softening Temperature:
82 °C
ISO 306, GB/T 1633

Material Properties

Technology

Nano reinforcement Technology
