PolyLite™ PLA Pro

面向专业用户的PLA
稳定可靠

Description

PolyLite™PLAPro是首款结合高韧性和高刚性的PLA,这款专业级PLA提供工程性能,同时不妥协于普通PLA的易打印性。PLApro是涵盖功能性原型、工装夹具以及终端零部件等应用领域的理想选择。

高冲击强度
易于使用
卓越的打印性

Characteristics

Printing Temperature:

190˚C - 220˚C

Bed Temperature:

30˚C - 60˚C

Printing Speed:

30mm/s -70mm/s

Fan:

ON

Direct Drive Retraction Distance:

3mm

Direct Drive Retraction Speed:

60mm/s

Indirect Drive Retraction Distance:

1mm

Indirect Drive Retraction Speed:

30mm

Drying Settings:

55˚C for 6h

Dry Settings Notes:

(Only if the material has absorbed moisture)

Colors

Colors

No SKUs found!

Series

Specifications

PolyLite™ PLA Pro

print
settings

Printing Temperature:
190˚C - 220˚C
Bed Temperature:
30˚C - 60˚C
Printing Speed:
30mm/s -70mm/s
Fan:
ON
Direct Drive Retraction Distance:
3mm
Direct Drive Retraction Speed:
60mm/s
Indirect Drive Retraction Distance:
1mm
Indirect Drive Retraction Speed:
30mm
Recommended Support Materials:
PolyDissolve™ S1/PolySupport™
Dry Settings:
55˚C for 6h
(Only if the material has absorbed moisture)

MEchanical Properties

(XY)Young's Modulus (MPa):
2932.2 ± 55.3 MPa
ISO 527, GB/T 1040
(Z)Young's Modulus (MPa):
2633.0 ± 117.4 MPa
ISO 527, GB/T 1040
(XY)Tensile Strength:
49.8 ± 0.4 MPa
ISO 527, GB/T 1040
(Z)Tensile Strength:
36.5 ±0.6 MPa
ISO 527, GB/T 1040
(XY)Elongation at break(%):
6.3 ± 0.9 %
ISO 527, GB/T 1040
(Z)Elongation at break(%)
2.4 ± 0.3 %
ISO 527, GB/T 1040
(XY)Bending Modulus (MPa):
2933.8 ± 78.3 MPa
ISO 178, GB/T 9341
(XY)Bending Strength (MPa):
77.9 ± 0.4 MPa
ISO 178, GB/T 9341
(XY)Charpy Impact Strength:
17.1 ±1.2 kJ/m2
ISO 179, GB/T 1043

Thermal Properties

Glass Transition Temperature:
62.0 °C
DSC, 10°C/min
Melting Temperature:
62.0 °C
DSC, 10°C/min
Heat Deflection Temperature
(1.8MPa):
57.6 °C
ISO 75 1.8MPa
Heat Deflection Temperature
(0.45MPa)
59.3 °C
ISO 75 0.45MPa
Vicat Softening Temperature:
62.7 °C
ISO 306, GB/T 1633

Material Properties

Technology

Jam-Free™ technology improves the heat stability of Polymaker’s PLA filaments with softening temperatures over 140 °C. As a result, Polymaker’s PLA filaments show minimal softening in the “cold end” and can melt rapidly once entering the heating zone, leading to excellent printing quality with zero risk of nozzle jams.
