PolyLite™ ABS

低气味ABS
坚固且耐用

Description

PolyLite™ ABS采用特殊本体聚合ABS树脂制成,与传统ABS树脂相比,其挥发性含量显著降低。它的打印质量优秀,且气味极小,兼具抗冲击性和耐温性(~100˚C)。PolyLite™ ABS是机械零件、机器人、功能性原型或家用电器零件的理想选择。

可机加工
耐热
抗冲击

Characteristics

Printing Temperature:

245˚C - 265˚C

Bed Temperature:

90˚C - 100˚C

Printing Speed:

30mm/s -50mm/s

Fan:

OFF

Direct Drive Retraction Distance:

3mm

Direct Drive Retraction Speed:

40mm/s

Indirect Drive Retraction Distance:

1mm

Indirect Drive Retraction Speed:

20mm

Drying Settings:

70˚C for 6h

Dry Settings Notes:

(Only if the material has absorbed moisture)

Colors

Colors

No SKUs found!

Series

Specifications

PolyLite™ ABS

print
settings

Printing Temperature:
245˚C - 265˚C
Bed Temperature:
90˚C - 100˚C
Printing Speed:
30mm/s -50mm/s
Fan:
OFF
Direct Drive Retraction Distance:
3mm
Direct Drive Retraction Speed:
40mm/s
Indirect Drive Retraction Distance:
1mm
Indirect Drive Retraction Speed:
20mm
Dry Settings:
70˚C for 6h
(Only if the material has absorbed moisture)

MEchanical Properties

(XY)Young's Modulus (MPa):
2246.6 ± 58.2 MPa
ISO 527, GB/T 1040
(Z)Young's Modulus (MPa):
2080.9 ± 92.7 MPa
ISO 527, GB/T 1040
(XY)Tensile Strength:
33.4 ± 0.6 MPa
ISO 527, GB/T 1040
(Z)Tensile Strength:
29.7 ± 0.3 MPa
ISO 527, GB/T 1040
(XY)Elongation at break(%):
17.9 ± 1.3 %
ISO 527, GB/T 1040
(Z)Elongation at break(%)
3.1 ± 0.3 %
ISO 527, GB/T 1040
(XY)Bending Modulus (MPa):
2127.2 ± 29.9 MPa
ISO 178, GB/T 9341
(XY)Bending Strength (MPa):
56.2 ± 0.3 MPa
ISO 178, GB/T 9341
(XY)Charpy Impact Strength:
18.0 ± 0.9 kJ/m2
ISO 179, GB/T 1043

Thermal Properties

Glass Transition Temperature:
101.1 °C
DSC, 10°C/min
Melting Temperature:
101.1 °C
DSC, 10°C/min
Heat Deflection Temperature
(1.8MPa):
98.2 °C
ISO 75 1.8MPa
Heat Deflection Temperature
(0.45MPa)
99.6 °C
ISO 75 0.45MPa
Vicat Softening Temperature:
103.9 °C
ISO 306, GB/T 1633

Material Properties
