Fiberon™ PA6-CF20 is a carbon fiber reinforced PA6 (Nylon 6) filament. The carbon fiber reinforcement provides significantly improved stiffness, strength and heat resistance with outstanding layer adhesion.
Fiberon™ PA6-CF20 is the same great formula as PolyMide PA6-CF, although Fiberon™ PA6-CF20 may print in a slightly darker black shade color than its predecessor.
Printing Temperature:
280˚C - 300˚C
Bed Temperature:
25˚C - 50˚C
Printing Speed:
30mm/s -60mm/s
Fan:
OFF
Direct Drive Retraction Distance:
3mm
Direct Drive Retraction Speed:
40mm/s
Indirect Drive Retraction Distance:
6mm
Indirect Drive Retraction Speed:
60mm
Drying Settings:
100˚C for 8h
Dry Settings Notes:
(Only if the material has absorbed moisture)
Annealing:
80˚C for 6h
No SKUs found!
Fiberon™ Series
Warp-Free technology
Fiber adhesion technology
